Multi Use Games Area with angled corner 24 x 12 : 1 fence high

We have created the reference J22209® in our "Multi-Use Games Areas" range. This activity equipment is accessible from 6 years.

The size of the module is: 24.50 m length, 12.70 m width, 3.90 m. high.

3 sports activities

Basketball x1

Football x1

Handball x1

Specifications

Age range:	6+
Size:	24.50 x 12.70 x 3.90 m

Equipment installation

Number of installers:	3
Installation time:	24:00:00
Concrete volume:	3.40 m3
Total weight:	1342.66 kg
Weight of the heaviest element:	27.36 kg

Environmental Indicators

Repairability

8.65 /10

Downloads

Technical fact sheet

Materials sheet*

JPEG Image

2D DXF

2D DWG

3D DWG

Certification

The products in our catalogues all comply with current European standards and are TÜV approved. Our website offers many additional configurations for which Proludic certifies compliance.

Video - Multi-Use Games Areas - Multi Use Games Area with angled corner 24 x 12 : 1 fence high - J22209®

Materials

The 102mm diameter posts are made of painted galvanised steel. The grained finish has a slightly undulating surface for increased scratch resistance. The caps are made of... painted aluminium. The fixing collars are made of painted aluminium. Read more

The panels are made of painted galvanised steel.

The basketball ring is made of galvanised steel.

The coloured panels are made from a 13mm thick compact material (HPL). Robust in construction, it has excellent weather and vandal resistance properties.
