Balancing trails - J5405-M

We have created the reference J5405-M in our "Balancing trails" range. This play equipment is accessible from 2 years. It can accommodate up to 60 users.

The size of the module is: 6.52 m length, 11.07 m width, 1.80 m. high. The free fall height (FFH) is 0.65 m.

Other finishes available

42 play functions

climbing
Climbing x2
Climbing develops the motor and psychomotor skills of the child who must show balance and assess risk to progress in their movement.
balancing
Balancing x12
Balancing involves learning to manage empty space in activities at height, hanging or on narrow surfaces.
getting across
Getting across x12
 Succeeding in this activity allows the child to gain self-confidence and make them want to progress in more complex traversing movements.
balancing
Balancing x4
getting across
Getting across x4
jumping
Jumping x1
walking
Walking x3
hanging
Hanging x2
This fun activity allows you to explore a new way of playing, of managing space and the void below.
climbing
Climbing x2
Climbing promotes dexterity, balance and coordination of movements. On the way up, the child learns to deal with height.
Show more

Specifications

Age range: 2 - 8
Number of users: 60 users
FFH : 0.65 m
Size: 6.52 x 11.07 x 1.80 m

Equipment installation

Number of installers: 2
Installation time: 40:00:00
Concrete volume: 3.40 m3
Surface: 114.00 m2
Total weight: 772.99 kg
Weight of the heaviest element: 18.43 kg

Environmental Indicators

Repairability

Repairability

9.44 /10

Certification

The products in our catalogues all comply with current European standards and are TÜV approved. Our website offers many additional configurations for which Proludic certifies compliance.
Side view
Side view
View from above
View from above

Materials

The 125mm diameter posts

The 125mm diameter posts are made of painted galvanised steel. The two-tone grey grained finish has a slightly undulating surface for increased scratch resistance. The caps... are made of injection moulded polyamide. Read more

The platform floors

The platform floors are made from a 18mm thick, non-slip polyethylene material.

The 16mm diameter ropes

The 16mm diameter ropes are made of galvanised steel cable covered with polyester. The cables are linked together and held in place by injected polyamide spheres.

The net fittings

The net fittings are made of polyamide. The fittings are composed of two distinct parts for ease of maintenance of individual strands.

Injected aluminium elements

Injected aluminium elements are fixed on the posts with self-drilling screws to provide links between the ropes and the posts.

Injection moulded polyamide fixings

Injection moulded polyamide fixings connect the posts with the platforms and the various play features. They are non-toxic, flameproof and U.V. resistant. The thickness of the polyamide... makes the equipment both strong and vandal resistant. Read more

The tubes

The tubes are made of 40mm diameter stainless steel, guaranteeing lasting durability and reliability of the equipment.

The climbing holds

The climbing holds are made of polypropylene. They are non-toxic, inflammable and shock and UV resistant.

The strap

The strap is made of 3 ropes linked together with aluminium pliers. Each rope, of 16mm diameter, is made up of galvanized steel cables covered in polypropylene.

The fixings

The fixings are made of stainless or plated steel and protected by anti-vandalism polyamide caps.
